HDMI-HDBaseT 6x6 4K PoH matrix

CUSTOMPRO-HUB16

New

HDMI-HDBaseT 6x6 4K PoH matrix

More details

CHF 4,295.00 tax excl.

Add to wishlist

Customer ratings and reviews

Nobody has posted a review yet

More info

HDMI-HDBaseT 6x6 4K PoH matrix

Advanced HDBaseT™ technology offering uncompressed sound and video with zero latency.
- Includes 6 x HDMI inputs that can be routed independently to 6 x HDBaseT outputs™
- Output 1 offers simultaneous HDMI and HDBaseT output™
- Extends HDMI up to 70m on a single CAT cable
- Supports UHD 4K video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
- Supports all industry standard video resolutions, including VGA-WUXGA and 480i-4K
- Supports all known HDMI audio formats, including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
- Web interface module for matrix control and configuration
- Supports two-way IR on all HDBaseT outputs™
- Control via front panel, IR, RS-232 and TCP/IP
- Supports The PoC (Power over Cable) to power HDBaseT compatible receivers™
- Third-party drivers are available for all major home control brands
- Advanced management of EDID
- Meets HDCP 2.2

- Video input connectors: 6 x HDMI Type A, 19 pins, female
- Video output connectors: 1 x HDMI Type A, 19 pins, female, 6 x HDBaseT™ RJ45 Connectors
- Port series RS-232: 1 x DB-9, female
- IR input ports: 7 x 3.5 mm stereo jack
- IR output ports: 6 x 3.5 mm mono jack
- Rack Mountable: Height of the 1U rack, rack ears included
- Case size (L x H x P): 437mm x 44mm x 377mm (without feet)
- Sending weight: 5.0 kg

Package content:
- 1 x Rack Mounting Kit
- 1 x Remote Control
- 6 x IR transmitters
- 7 x IR Receivers
- 1 x cable series - DB9 to DB9
- 1 x IR control cable - 3.5mm-3.5mm cable
- 1 x Quick Reference Guide
- CH power cables
